Introducing the VP32AW32

The VP32AW32 is a member of the VIPER family of system on a board modules.

The VIPER VP32AW32 module is a complete stand alone microcontroller based system.  In addition to the Freescale MC9S08AW32 high performance, low power microcontroller, the module includes the crystal, voltage regulator, BDM debug port, dual RS232 transceiver and 2K EEPROM.

Small 1.63” x 0.82”, 32-pin DIP package

Peripherals Include: 32KB in-circuit re-programmable Flash 2KB Ram 8 channel, 10-bit Analog to Digital converter (ADC) SPI communication port I2C communication port (used for on-board EEprom) 2 UART communication ports 6 Keyboard interrupt inputs 6 Timer channels with input capture, output compare and PWM functions Up to 24 General purpose I/O Watch dog timer Keyboard interrupts Internal Clock generator Low voltage detection BDM (background debug module)
